Ground conveyor

首 頁 >> Conveying Equipment >> Ground conveyor

Ground conveyor

The ground conveyor is a common continuous conveying device with the advantages of operation, simple maintenance and long service life.
Ground conveyor

Ground conveyor,Ground conveying equipment

Description

The ground conveyor is a common continuous conveying device with the advantages of operation, simple maintenance and long service life.

Classification table

The types of ground conveyors produced by our factory mainly include:

(1) Plate conveyor: The plate conveyor mainly consists of chain plate device, driving device, rail frame, track, head wheel assembly and tail wheel assembly. It has the advantages of small footprint, safe operation and reliable use. This product has been widely used in some washing machines, refrigerators, air conditioners and automobile assembly, engineering machinery assembly and other industries.

Ground conveyor
Ground conveyor



Classified by section
Classified by load size

Classified by chain pitch

Classified by platen width

Classified by type of trolley wheel

Classified by ear plate

Single chain single channel

Light-weight type

200mm

300

Rolling type with rolling bearings

Single ear plate type

Single chain double channel

Heavy type

250mm

600

Sliding type with oil-free lubricated bearings

Double ear plate type

Double chain single channel

Extra heavy type

400mm

1000

Bearingless sliding

Earless plate type

Double chain double channel





2000











3000







(2) Roller conveyor:

Roller conveyors are conveyor equipment that is widely used in various industries. The device is simple in construction and easy to maintain and use. It is suitable for continuous conveying and accumulation of finished articles. With various auxiliary special machines, different process requirements (flip, transfer, branching, confluence, steering) of the workpiece on the production line can be completed.



Main Technical Parameters

Load

Roller diameter(mm)

Station load(kg)

Belt width

Roller pitch

Light-weight type

42

50

400

75

Medium type

60

100

600

130

Heavy type

60

500

800

150

Extra heavy type

76

1000

1200

200



(3) Ground push conveyor: Ground push conveyor is a conveying device that installs the whole machine (drive, tension, track, chain) under the ground. The transported workpiece is placed on the craft (carrying) trolley, and the craft trolley is pushed by the pusher or pusher trolley mounted on the traction chain to operate on the ground (or the track laid along the ground). This kind of conveyor is mostly used in various types of pipelines on the ground multi-station, to complete various process requirements (such as pre-treatment, painting, assembly, debugging, inspection, etc.) of the workpiece during operation.



Main Technical Parameters

Bicycle carrying capacity(kg)

Minimum horizontal radius of gyration(mm)

Running speed(m/min)

Chain pitchmm

Power(KW)

500

1000

0.3-10

100

1.1-5.5



(4) Sliding conveyor: The sliding conveyor is a storage and transportation equipment on the production line of welding, painting and final assembly in the automotive industry, which has been widely used in recent years. The roller bed fixed on the ground serves as a power source, and relies on the friction force to move the carcass placed above it; the workpiece to be transported is placed on the carcass. The “flexible transfer” during the transportation and transfer of the workpiece is realized. It eliminates the synchronous control problem that must be solved between other chain drive ground conveyors, and improves the reliability of the system work. The machine can realize special functions such as line translation, right angle turn, vertical lift, horizontal rotation and storage of the workpiece to be transported. Flexible wiring and strong production adaptability. The main equipment of the system: power roller, electric travel machine, rotary table, lift, unpowered roller bed, chain shift machine, single (double) chain conveyor. Among them, the chain conveyor adopts t=160 plate chain, and the ultimate tensile load is 160kN.



Main Technical Parameters

Load capacity of pry body(kg)

Pry body running speed(m/min)

Rotation speed(r/min)

Transverse speed(m/min)

Pry height

200-1000

0.5-12

0.5-2

5-20
